Eaton BR816B200RF BR 200 Amp 8-Space 16-Circuit Outdoor Main Breaker Loadcenter with Cover Gray

Voltage

120/240

Mounting Type

Plug In

Number of Outlets

0

Warranty

10 years

Certifications

Made in the USA, UL

Amperage

200 Amp

Phase

1

Manufacturer Warranty

10 years

Certifications and Listings

ANSI Certified, UL Listed

Indoor/Outdoor

Outdoor

Load Center Type

Main Breaker

Load center width (in.)

14.31

Maximum Amperage

200

Maximum Voltage

120/240 Volt

Number of Circuits

16

Number of Phases

1

Number of Spaces

8

Pack Size

1

UNSPSC

39121101

Wire Size

#2 AWG to 300 kcmil (Copper, Aluminum)

Certification

UL Listed

Enclosure Type

Rainproof

Series

BR

Mount Type

Surface

Max Number of Circuits

16

Product Overview

Specially designed for easy installation, Eaton’s BR load centers house the branch circuit breakers and the wiring required to distribute power to individual circuits. The panels serve as main breaker for service entrances. The main breaker protects the main entire panel and can be used as a service disconnect. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets. The BR816B200RF is a 200 Amp outdoor main breaker with 8 spaces and 16 circuits.

• Amperage rating: 200
• Bus material: aluminum
• Rated NEMA 3R for outdoor use
• Feed type: bottom or top which allows for straight-in wiring that saves labor and material
• Interrupt rating: 25 kAIC
• Mounting: combination
• Number of circuits: 16
• Number of spaces: 8
• Phase: single-phase
• Tangential center knockout easier installation for conduit applications
• 2/0 lug easily removable and can be installed in any location on the neutral bar
• Neutral bus (strap) is easily removable for sub-panel applications
• Bonding Z-strap provides easy field conversion for service entrance applications
• Twin neutral bars minimum 150% neutral capacity
• Steel back pan provides solid and reliable breaker mountingsingle piece design for stability and durability
• Single keyhole mounting – 1 keyhole at the top and bottom provides easier mounting and leveling
• Used with: type BR breakers
