Eaton BRP20B100 Load Center, 48 -Pole, 100 A, 20 -Space, 40 -Circuit, Main Breaker, Plug-On Neutral, Type BR

• Knockout locations for additional access
• Optimized knockouts easier to remove
• Smooth case edges provides a more professional look and fee
• Top or bottom feed straight-in wiring saves labor and material
• One panel for either top or bottom applications
• 2/0 lug easily removable and can be installed in any location on the neutral bar
• Compact design for easier wiring improved wireway access
• Provides a clean gutter space
• Inboard neutral increases gutter space to allow for the professional installation of conductors
• Excellent conductivity and corrosion resistance

Voltage

240/120, 240/120 volts

Warranty

10 years

Pack Size

1

Manufacturer Warranty

10 Year

Certifications and Listings

UL Listed

Indoor/Outdoor

Indoor

Load Center Type

Main Breaker

Load center width (in.)

16

Maximum Amperage

100, 100 amp

NEMA Configuration

NEMA 1

Number of Circuits

40

Number of Spaces

20

UNSPSC

39121101

Returnable

Yes

UL Listed

Yes

Defective Code

A

Maximum Number of Circuits

20 circuits

Sub Brand

Cutler-Hammer

Mounting Type

Flush Surface

Indoor or Outdoor

Indoor

Volts

120/240 V

Packaging Type

Boxed

Depth

3-7/8″

Alternative UPC

786689053154

Product Type

Main Breaker Load Center and Meter Socket

AMPS

100 amps

Each Weight

21.600 LB

Velocity

X

Height

4.50

ECCN

EAR99

Brand

Eaton

Width

16.00

Country Origin Code

US

Length

24.50

Hazardous Material

No

Application

For Residential and Light Commercial Use

Number of Phases

1

Number of Poles

48

Cable Size

4 to 1/0 AWG

Interrupt Rating

10 kaic

Enclosure Type

NEMA 1

Breaker/Load Center Type

Main Breaker Plug-On Neutral Type BR

Nomenclature

BRP20B100/BR2040B100 LDCNTR 10

Bus Bar Material

Aluminum

Current Rating

100 A

Wire Size

#4 AWG to 1/0 2

Amperage

100

Phase

Single

Certification

UL Listed

Series

BR

Mount Type

Bolt On

Max Number of Circuits

40

Product Overview BRLC 100A MN 20/40 CR
Specifications:

Includes: Cover

EATON Load Center, 120/240 VAC, 100 A, 1 ph, 20 Spaces, 48 Pole, 40 Circuits, Main Breaker, Plug-On Neutral, Type BR Breaker/Load Center, 10 kAIC Interrupt, #4 to 1/0 AWG Cable, Bus Bar Material: Aluminum, NEMA 1 Enclosure, Flush, Surface Mounting, Includes: Cover
